SOETECK SY-VRLA Series 12V AGM Battery

The SOETECK SY-VRLA Series 12V AGM Battery provides reliable, high-performance power with a lifespan of up to 12 years and a self-discharge rate of less than 99.9%. It operates safely across a temperature range of -40°C to 60°C, making it suitable for diverse energy storage applications.

No data available


Product Overview

The SOETECK SY-VRLA Series 12V AGM Battery is designed for high-performance power solutions in various industries. With reliable energy storage capabilities, it is ideal for both commercial and residential applications.

Featuring a low self-discharge rate and a long lifespan of up to 12 years, this battery maintains its charge, making it perfect for emergency backup systems and renewable energy installations. The advanced AGM technology ensures safe operation without risk of leaks, making it suitable for sensitive environments like telecommunications and IT systems.

Additionally, this series boasts high charging efficiency over 99.9% and operates effectively in a temperature range from -40°C to 60°C. Overall, the SOETECK SY-VRLA Series 12V AGM Battery delivers a dependable and cost-effective energy solution for modern power needs.

Product Features

High Performance Index

  • Charging Efficiency: Achieves a peak efficiency of over 99.9% during charge cycles, significantly reducing electricity costs and optimizing battery performance.
  • Long Lifespan: Ensured longevity of up to 12 years under regular float charging conditions, reducing the need for frequent replacements.

Low Self-Discharge Rate

  • Self-Discharge: Features a remarkable self-discharge rate of less than 3% per month at 20°C, making it ideal for emergency power systems that require reliable readiness.

Robust Load Handling

  • High Discharge Capacity: Capable of sustaining continuous loads up to 500A and achieving peak discharges of 1600A for 5 seconds, suitable for industrial applications that demand burst energy.

Wide Operating Temperature Range

  • Temperature Range: Functions optimally within a temperature spectrum of -40°C to 60°C, ensuring reliable performance in extreme environments.

Enhanced Safety Features

  • Maintenance-Free Design: Made with AGM technology to prevent electrolyte leakage, eliminating the need for water maintenance, and ensuring user safety.
  • Leakproof Construction: Designed to prevent spills and allow for versatile installations, ideal for sensitive electronic environments.

Typical Applications

  • Uninterruptible Power Supply (UPS)
  • Renewable Energy Storage
  • Telecommunication Systems
  • Electric Mobility Solutions
  • Backup Power for Data Centers

Model Overview

The SOETECK SY-VRLA Series 12V AGM Battery includes models with capacities from 5Ah to 250Ah, meeting a range of energy storage needs. All models feature a lifespan of up to 12 years and a charging efficiency exceeding 99.9%. The maintenance-free design eliminates the need for electrolyte monitoring, simplifying operation.

The NPG12-5Ah is suitable for small UPS systems, while the NPG12-100Ah serves as a versatile option for everyday energy needs. For high-demand applications, the NPG12-250Ah provides a maximum discharge capability of 1600A for 5 seconds, making it ideal for industrial uses that require quick bursts of energy.

The series allows users to select the optimal model based on their specific requirements, ensuring performance and efficiency.

ModelsNominal VoltageRated CapacityLengthWidthHeightTotal HeightAppox.Weight
SY-GFM1200512V5Ah (20hrs/25℃)90mm70mm101mm107mm1.50 kg
SY-GFM1200712V7Ah (10hrs/25℃)151mm65mm94mm100mm1.97 kg
SY-GFM1200912V9Ah (10hrs/25℃)151mm65mm94mm100mm2.50 kg
SY-GFM1201212V12Ah (10hrs/25℃)151mm98mm95mm101mm3.30 kg
SY-GFM1201712V17Ah (10hrs/25℃)180mm77mm167mm167mm4.80 kg
SY-GFM1202012V20Ah (10hrs/25℃)180mm77mm167mm167mm5.25 kg
SY-GFM1202412V24Ah (10hrs/25℃)166mm126mm141mm174mm6.90 kg
SY-GFM1203812V38Ah (10hrs/25℃)197mm165mm174mm174mm11.00 kg
SY-GFM1205512V55Ah (10hrs/25℃)230mm138mm208mm212mm15.00 kg
SY-GFM1206512V65Ah (10hrs/25℃)350mm166mm58mm19mm18.00 kg
SY-GFM12100A12V100Ah (10hrs/25℃)330mm114mm193mm210mm27.30 kg
SY-GFM12100B12V100Ah (10hrs/25℃)407mm173mm208mm238mm28.50 kg
SY-GFM1212012V120Ah (10hrs/25℃)407mm173mm208mm238mm32.50 kg
SY-GFM1215012V150Ah (10hrs/25℃)485mm172mm240mm240mm40.00 kg
SY-GFM1220012V200Ah (10hrs/25℃)522mm238mm218mm222mm52.80 kg
SY-GFM1225012V300Ah (10hrs/25℃)521mm269mm220mm224mm66.80 kg

Product Specifications

Data coming soon! Please revisit this page later, or reach out to us for additional details.
