February 25, 2025
The SOETECK 1U Rectifier Module series is designed for high power density applications, offering reliable power conversion with input voltages ranging from 85Vac to 300Vac and adjustable output voltages between 42Vdc and 58Vdc. With efficiency ratings exceeding 95%, these modules minimize energy loss, making them suitable for demanding environments such as telecommunications and data centers. Equipped with essential protections like output short-circuit and over-voltage defenses, they ensure safe operation. The built-in CAN bus communication enhances system management through remote monitoring.
| No data available |
The SOETECK 1U Rectifier Module series is engineered for high power density applications, providing reliable and efficient power conversion. With an input voltage range of 85Vac to 300Vac and an adjustable output voltage from 42Vdc to 58Vdc, these modules are designed to meet the demands of various industrial and commercial environments.
These rectifier modules deliver exceptional performance with efficiency ratings exceeding 95% under typical load conditions, ensuring minimal energy loss and reduced operational costs. The robust design supports a maximum output power of 3000W to 4000W, making them suitable for applications in telecommunications, data centers, and renewable energy systems.
Advanced protection features, including output short-circuit protection, over-voltage protection, and thermal management, ensure safe operation under varying conditions. The modules also incorporate CAN bus communication capabilities, allowing for remote monitoring and management, which enhances operational efficiency and system integration.
Designed to withstand harsh environments, the SOETECK 1U Rectifier Module series is built with a compact form factor and robust construction, making it an ideal choice for high-demand applications where reliability and performance are critical.
The SOETECK 1U Rectifier Module series includes two models: the SY-RM4850M and the SY-RM4875M. The SY-RM4850M is designed for applications requiring up to 3000W output power, making it suitable for medium-load scenarios. It operates efficiently with an input voltage range of 85Vac to 300Vac and features advanced protection mechanisms to ensure safe operation. In contrast, the SY-RM4875M offers a higher output capacity of 4000W, making it ideal for high-demand applications. Both models share similar input voltage specifications and efficiency ratings, ensuring they meet the rigorous demands of modern power systems.
| Models | Rated Output Power | Input Voltage Range | Output Voltage Range | Efficiency | Power Factor | Wiring |
|---|---|---|---|---|---|---|
| SY-RM4850M | 3000 W | 85Vac to 300Vac | 42Vdc to 58Vdc | ≥95% | ≥0.99 @ 220Vac 20%-100% Load | -40°C to +55°C |
| SY-RM4875M | 4000 W | 85Vac to 300Vac | 42Vdc to 58Vdc | ≥96.6% | ≥0.99 @ 220Vac 20%-100% Load | -40°C to +50°C |
Data coming soon! Please revisit this page later, or reach out to us for additional details.
