data center

In-Row Cooling

Precision cooling for data centers and industrial facilities.

The In-Row Cooling system is designed for high-density data centers, utilizing eco-friendly R410A refrigerant to deliver exceptional energy efficiency and intelligent control. Its cooling capacity is adjustable from 20% to 100%, accommodating various load requirements. Featuring a 7-inch touchscreen, it displays real-time data and operating conditions.

Showing all 3 results

SOETECK Chilled-water in-row cooling system -4SOETECK Chilled-water in-row cooling system -3SOETECK Chilled-water in-row cooling system -1SOETECK Chilled-water in-row cooling system -2

SOETECK Chilled-Water In-Row Cooling System, 28.9kW – 65.8kW Capacity

The SOETECK in-Row Chilled-water Cooling System, offering capacities from 28.9kW to 65.8kW, is an energy-efficient cooling solution for modular and containerized data centers. Featuring motorized ball valves, high-performance EC fans, and a compact design with 300mm and 600mm width options, it delivers reliable and precise cooling …

Get QuotationView Details
ModelsCooling CapacitySensible CapacityAir VolumeWidthDepthHeightWeight
025RC-7/1241.0kW40.8kW4800m³/h300mm1100mm2000mm190kg
025RC-10/1536.8kW36.8kW4800m³/h300mm1100mm2000mm190kg
025RC-13/1832.9kW32.9kW4800m³/h300mm1100mm2000mm190kg
045RC-7/1265.4kW65.4kW9000m³/h600mm1100mm2000mm330kg
045RC-10/1559.0kW59.0kW9000m³/h600mm1100mm2000mm330kg
045RC-13/1852.4kW52.4kW9000m³/h600mm1100mm2000mm330kg
065RC-7/1293.2kW93.2kW11400m³/h600mm1100mm2000mm400kg
065RC-10/1584.0kW84.0kW11400m³/h600mm1100mm2000mm400kg
065RC-13/1874.8kW74.8kW11400m³/h600mm1100mm2000mm400kg
SOETECK air-cooled packaged in-row cooling system -1SOETECK air-cooled packaged in-row cooling system -2SOETECK air-cooled packaged in-row cooling system -3SOETECK air-cooled packaged in-row cooling system -4

SOETECK DX Packaged in-Row Cooling System, 5.6kW–10.8kW Capacity

The SOETECK in-Row DX Package Cooling System, offering a capacity range of 5.6kW to 10.8kW, is a compact and energy-efficient cooling solution for data centers with limited space for outdoor condensers. Featuring dynamically modulated cooling, high-performance EC fans, and a built-in condenser, it delivers precise thermal …

Get QuotationView Details
ModelsCooling CapacitySensible CapacityAir VolumeWidthDepthHeightWeight
S005PA5.6kW5.6kW2000m³/h300mm1200mm2000mm210kg
S007PA7.6kW7.6kW2250m³/h300mm1200mm2000mm213kg
S010PA10.8kW10.8kW2500m³/h300mm1200mm2000mm233kg
SOETECK air-cooled in-row cooling system -5SOETECK air-cooled in-row cooling system -6SOETECK air-cooled in-row cooling system -3SOETECK air-cooled in-row cooling system -4

SOETECK DX Air-cooled In-Row Cooling System, 5.6kW–90.1kW Capacity

This Air-cooled DX Precision AC is designed for in-row cooling system in data centers, offering a capacity range of 5.6kW to 90.1kW. With dynamically modulated cooling, EC fans, and precision controllers, it ensures stable and efficient operation. Its flexible, row-mounted design and optional features make it a …

Get QuotationView Details
ModelsCooling CapacitySensible CapacityAir VolumeWidthDepthHeightWeight
007RA7.5kW7.5kW2300m³/h300mm1100mm2000mm213kg
012RA12.6kW12.6kW2500m³/h300mm1100mm2000mm233kg
017RA17.8kW17.8kW4500m³/h300mm1100mm2000mm253kg
020RA21.5kW21.5kW4920m³/h300mm1100mm2000mm258kg
025RA25.5kW25.5kW5100m³/h300mm1100mm2000mm260kg
030RA31.5kW31.5kW6000m³/h300mm1100mm2000mm320kg
040RA41.5kW41.5kW8100m³/h600mm1100mm2000mm360kg
050RA50.5kW50.5kW10200m³/h600mm1100mm2000mm420kg
065RA65.5kW65.5kW12100m³/h600mm1100mm2000mm460kg
075RA75.5kW75.5kW13600m³/h900mm1100mm2000mm540kg
090RA90.5kW90.5kW16200m³/h900mm1100mm2000mm620kg
